Ballast water treatment systems at a glance

With the ratification of the Ballast Water Management Convention, shipowners are pressed to decide which treatment systems to choose. For manufacturers keen to be selected, attaining type approval by the U.S. Coast Guard can be a deciding factor. DNV GL provides comprehensive review on the issue.

For operators with vessels that discharge ballast water in international waters, the BWM Convention, entering into force on 8 September 2017, means that they must have a treatment system installed on their vessels within five years. The specific deadline depends on the next renewal survey of a vessel’s International Oil Pollution Prevention (IOPP) certificate.

For many operators trying to decide which type of system to install, one of the most important questions is: Does the system meet the U.S. Coast Guard (USCG) requirements? In late 2016, the manufacturers Alfa Laval, Optimarin and OceanSaver became the first to be awarded U.S. Coast Guard type approval certificates for their ballast water treatment systems.

The USCG officially appointed DNV GL as an Independent Laboratory (IL) to perform type approval testing of ballast water treatment systems (BWTS) in 2013. There are now five “Independent Laboratory” accreditations for BWTS.

DNV GL has completed land-based testing cycles for four further manufacturers. Successfully passing land-based testing is a good indication that the systems could also meet the U.S. Coast Guard’s requirements, once they have undergone shipboard testing.“Land-based testing really challenges the efficacy of the systems. In 15 test cycles, they expose the systems to 1,000 times more large organisms and ten times more medium-sized organisms than shipboard testing. If all goes to plan, another four systems could be approved in the first half of 2018.” Martin Olofsson, Senior Principal Engineer, Environmental Protection DNV GL – Maritime Approval of Ship Systems and Components said.

DNV GL cites a series of factors for choosing the best-suited treatment system:

• What ship type is it?
• Does the vessel operate in fresh or brackish water?
• Does it primarily sail in cold or temperate waters?
• Will the system have to work in high-turbidity conditions, meaning water that contains a lot of clay, algae or silt?

All these questions are very important for making the right choice. The five treatment systems which already hold or are soon expected to hold a USCG type approval certificate include UV systems, electrolytic systems and chemical injection systems.
